AT130D 3-Axis Double Sensor Electro-optical Pod With AI

The AT130D electro-optical pod is composed of an uncooled infrared thermal imaging camera, a 33x continuous zoom visible light camera, a three-axis servo stabilization platform and an image tracker. It has the characteristics of light weight, high stability and precision, high integration, automatic target recognition, automatic tracking, etc. It can be used on medium and small UAVs to complete day and night reconnaissance and surveillance of target areas.

The electro-optical pod uses uncooled infrared thermal imaging cameras and visible light cameras to detect, identify and track ground targets all day long, and output infrared and visible light videos in real time for mission execution personnel to view. It mainly used in reconnaissance, border patrol, personnel search and rescue, forest fire prevention and other scenarios.

• Features

a) It has the functions of automatic recognition and automatic tracking of typical targets;

b) Equipped with self-test and fault reporting functions;

c) It has long-wave infrared and visible light band detection capabilities and can output infrared images and visible light images;

d) Visible light has optical zoom, auto focus, manual focus, fog penetration and low illumination functions;

e) Infrared has 0 to 4.0 times digital zoom and 6 color palette switching functions ;

f) Ability to move with three degrees of freedom in azimuth, pitch and roll;

g) Equipped with multiple working modes such as heading lock/manual search/follow-up/attitude stabilization/tracking;

h) It has the ability to isolate carrier disturbance and stabilize the line of sight;

i) It has the function of locking/unlocking the target, and after locking the target, the pod output image is an image with a tracking frame;

j）It has automatic target tracking function, can automatically track targets, and has the ability to resist natural interference;

k）Equipped with memory tracking function, the target can be captured again in a short time after being temporarily lost;

l) It has the function of adjusting the size of the wave gate;

m) With tracking point switching function;

n) It can communicate with the control station in two directions through the serial port/100M network (U DP ) , and can output system working status, camera working status, optical axis position and other information;;

o) Equipped with 100M network video output interface ( RTSP protocol) ;

p) With photo and video functions ;

q) The product has a quick release function;

• Application

— Police law enforcement, Power inspection, Security inspection, Rescue & search, Fire fighting.

Thermal Infrared Imager
Detector Type	Uncooled focal plane detector
Working band	8μm～14μm
Detector resolution	640×512
Pixel size	12μm
Lens focal length	35mm
FOV	12.5°×10° (±5%)
False color	6 types
Digital zoom	1.0 ～ 4.0X
Noise equivalent temperature difference	NETD≤50mK
Minimum resolvable temperature difference	MRTD≤500mK
Visible Light
Resolution	1920×1080
Response band	0.4μm～0.9μm
Pixel size	2.8μm
Optical zoom	33 X

Visible Light
Focal length	4.8 mm～158 mm
FOV	58.9 °～ 2.4 °
Zoom mode	Auto focus, manual focus
Minimum illumination	0.01 Lux
System Parameters
Image tracking	Automatically track selected targets
AI recognition	Automatically detect and identify typical targets
Temperature measurement function	Optional
Rated working voltage	24V DC
Supply voltage range	11V~36V DC
Power	Stable power consumption: ≤30W (24V DC power-on peak current ≤5A)
Weight	≤1.1Kg
Volume	≤130 mm×135 mm×212 mm
Arm type	Inclined arm
Quick release type	With quick release

Servo Platform
Azimuth Angle	360°×n (360° continuous rotation)
Pitch Angle	-110 °～+ 45 ° (upward is positive)
Roll Angle	– 40 °～ + 4 0°
Frame angle accuracy	≤0.3°(1σ)
Stable accuracy	≤0.1mrad（1σ）
Maximum turning speed	Azimuth ≥50°/s, pitch ≥50°/s
Maximum turning acceleration	Azimuth ≥20°/s², pitch ≥20°/s²
Interface
Control interface	RS232/TTL/ RS422/100M network (optional)
Video interface	100M network
Storage interface	≤128G memory card (Mini SD card)
Image format / Video format	jpg format / avi format
Arm type	Straight arm
Quick release type	With quick release

Operating Ambient
Operating Temperature	-20°C～＋ 55 °C (-40°C optional) , Can fly in light rain
Storage Temperature	-45 ℃ ～+ 60 ℃
Vibration conditions	The acceleration is 2g; the three directions of vertical, horizontal and longitudinal are 30 minutes each.
Shock conditions	Peak acceleration 20g, duration 11ms
